Vibro cast crucibles
The largest capacities in the range — cast and vibration-compacted in high purity alumina, up to 1,000 kg of steel.
Key benefits
Talk to a Technical ExpertCapacity beyond pressing
Vibro casting reaches capacities up to 1,000 kg of steel, well beyond the 265 kg ceiling of the pressed range.
Cast in high purity alumina
Cast in high purity alumina, matched to your alloy, furnace and melt size.
Round and flat bottomed forms
Made in round and flat bottomed forms, with pouring spouts, ladles and bezels also cast to order.
Inspected before dispatch
Every casting is individually inspected by qualified inspectors, with kiln batch numbers giving full traceability.
The vibro casting process
Vibro casting forms the crucible by compacting a refractory mix into a mould under vibration, building solid, consistent walls at sizes beyond the largest pressed crucibles.
- Forming
- Compacted into the mould under vibration
- Material
- High purity alumina
- Capacity range
- Up to 1,000 kg of steel
Applications, from bulk air melting to vacuum furnace work
Vibro cast crucibles serve foundries, refiners and manufacturers whose melt sizes have outgrown the pressed range.
- Users
- Foundries, refiners and manufacturers
- Material
- Alumina, air and vacuum melting
- Capacity range
- Up to 1,000 kg of steel
Crucible materials
Browse all crucibles
Alumina Crucibles
The workhorse of the range. High purity alumina handles both air and vacuum induction melting, with the thermal shock resistance and smooth, non-wetting surface the investment caster relies on.
Round and flat bottomed forms
Vibro cast in both round and flat bottomed forms, sized to your furnace and pour.
Spouts, ladles and special shapes
Pouring spouts, transfer ladles and special shapes cast to order alongside the crucibles.
Capacities up to 1,000 kg of steel
Vibro cast crucibles are made in round and flat bottomed forms, at capacities up to 1,000 kg of steel.
- Forms
- Round and flat bottomed
- Range
- Up to 1,000 kg of steel
- Also cast to order
- Pouring spouts, transfer ladles, special shapes
Technical data
Talk to a Technical ExpertVibro cast round bottomed crucibles
| Drg No | ID | OD | IL | OL | Full capacity, kg of steel |
|---|---|---|---|---|---|
| 901 | 320 | 360 | 600 | 650 | 330 |
| 902 | 380 | 425 | 640 | 700 | 500 |
| 903 | 450 | 500 | 660 | 720 | 730 |
| 904 | 480 | 530 | 700 | 760 | 850 |
| 905 | 520 | 575 | 700 | 760 | 1,000 |
All dimensions in mm. Drg No: drawing number. ID: inside diameter. OD: outside diameter. IL: inside length. OL: overall length.
The measurable difference
Every part we make is individually inspected before it leaves the works — the same standard we have held for fifty years.
100%
Individually inspected
50 years
Manufacturing refractories in Britain
1,000 kg
Largest crucible capacity
Frequently asked questions
Send your alloy, furnace type and requirements with an enquiry and our technical team will advise.
Vibro cast crucibles are made in high purity alumina. For other materials and smaller capacities, crucibles are isostatically pressed — our technical team will match one to your process.
